| Brand & Model | ||
| Brand | Gigabyte | |
| Series | H61 | |
| Model | H610M H | |
| Supported CPU | ||
| CPU Type | LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with CPU |
|
| Chipsets | ||
| Chipset | Intel H610 Express Chipset | |
| Memory | ||
| Number of Memory Slots | DDR5 2 Memory Slots | |
| Maximum Memory Supported | up to 64 GB (32 GB single DIMM capacity) of system memory | |
| Channel Supported | Support for DDR5 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules Dual-channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
|
| Graphic | ||
| Graphic | Integrated Graphics Processor-Intel® HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz Support for the HDMI 2.1 version and HDCP 2.3. Support native HDMI 2.1 TMDS compatible ports |
|
| Expansion Slots | ||
| Expansion Slots | CPU: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 Chipset: 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
|
| Storage | ||
| Storage | Chipset: 1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support) 4 x SATA 6Gb/s connectors |
|
| Network | ||
| LAN | Realtek GbE LAN chip (1 Gbps/100 Mbps) | |
| Audio | ||
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel 1 x front panel audio header 2 x audio jacks |
|
| BIOS | ||
| BIOS | 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Ports | ||
| USB Ports | Chipset: 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) 4 x USB 2.0/1.1 ports on the back panel Chipset+USB 2.0 Hub: 4 x USB 2.0/1.1 ports available through the internal USB headers |
|
| Internal Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x RGB LED strip header 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper |
|
| Special features | HDMI 1x HDMI D-Sub (s) 1x D-Sub port |
|
| Warranty | ||
| Warranty | 3 years | |
| Form Factor | ||
| Form Factor | Micro ATX Form Factor; 23.0cm x 21.5cm | |
| Others | ||
| Bundled Software | Norton Internet Security (OEM version) LAN bandwidth management software |
|
| Special feature | Support for APP Centre Support for Q-Flash Support for Xpress Install |
|
The GIGABYTE H610M H V2 DDR5 Intel motherboard is a reliable, high-performance solution for modern PC builds in Bangladesh.
Powered by the Intel H610 Express chipset, this micro-ATX motherboard supports
14th-, 13th-, and 12th-generation Intel processors via the LGA1700 socket,
ensuring excellent compatibility and performance for gaming, office work, and
multitasking.
It features dual DDR5 RAM slots, supporting up to 64GB of
memory and speeds up to 4800MHz (OC), resulting in faster responsiveness and
improved system efficiency. The motherboard features HDMI and D-Sub graphics
outputs, making it suitable for high-quality display connections.
The Gigabyte H610M H V2 features Realtek GbE LAN for stable
internet connectivity and Realtek High-Definition Audio supporting
2/4/5.1/7.1-channel sound for immersive audio performance. Its durable
Micro-ATX design fits easily into small PC cases. Backed by a 3-year warranty,
this motherboard is an excellent choice for building a reliable Intel DDR5 desktop
PC in Bangladesh.
